Tuoren Butterfly IV Cannula
- Design: Winged IV catheter (Butterfly type) for secure skin fixation
- Needle & Catheter: Back-beveled siliconized needle with kink-resistant FEP fluoropolymer catheter
- Gauges Available: 16G (Grey), 18G (Green), 20G (Pink), 22G (Blue), 24G (Yellow), 26G (Violet)
- Key Clinical Advantage: Flexible textured wings allow shallow-angle venipuncture in fragile or superficial veins
- Regulatory Compliance: DRAP registered, ISO 13485, CE marked for institutional hospital supply
- Description
- Additional information
Description
Tuoren Butterfly IV Cannula (Winged Type) is a sterile, single-use intravenous catheter engineered for smooth, secure vascular access without the bulk of a top injection port. Supplied complete with an integrated Heparin Cap for convenient heparin locking and intermittent medication administration, the Tuoren butterfly cannula features flexible stabilization wings, a precision back-bevel siliconized needle, and a kink-resistant PTFE catheter, delivering trauma-free cannulation across surgical wards, pediatrics, and emergency centers in Pakistan.
CE Mark Approved
DRAP Registered (Form-5A / Class IIb)
Includes Heparin Cap
EO Sterile Packaging
Technical Specifications & Design Architecture
| Product Line | Tuoren Butterfly IV Cannula (Winged Type, Non-Ported) |
| Closure Configuration | Equipped with Pre-fitted Sterile Heparin Cap (Yellow Injection Stopper) |
| Catheter Material | Medical Grade PTFE (Teflon) / FEP with embedded radio-opaque stripes for radiographic tracking |
| Needle Metallurgy | Siliconized AISI 304 surgical stainless steel with ultra-sharp back-bevel geometry |
| Stabilization Wings | Foldable, flexible butterfly wings designed for flat, low-profile fixation against skin |
| Flashback Chamber | Optically clear chamber with porous hydrophobic filter for instant blood return confirmation |
| Gauge Range | 16G, 18G, 20G, 22G, 24G, 26G (ISO standard color coding) |
| Packaging Configuration | 50 Pcs per Inner Dispenser Box | 1,000 Pcs per Master Shipping Carton (20 boxes/carton) |
| Sterilization Method | 100% Ethylene Oxide (EO Gas), Non-pyrogenic & Non-toxic |
| Regulatory Standards | CE Marked, ISO 13485:2016, DRAP Registered (Class IIb Medical Device) |
Gauge Specifications & Infusion Flow Rates
| Gauge | ISO Color | Dimensions | Flow Rate | Clinical Speciality |
|---|---|---|---|---|
| 18G | Green | 1.3 mm x 45 mm | 90 ml/min | Blood Transfusion & Surgery |
| 20G | Pink | 1.1 mm x 32 mm | 61 ml/min | General Adult Ward Infusions |
| 22G | Blue | 0.9 mm x 25 mm | 36 ml/min | Geriatric & Oncology Infusions |
| 24G | Yellow | 0.7 mm x 19 mm | 20 ml/min | Pediatric & Fragile Veins |
| 26G | Purple | 0.6 mm x 19 mm | 15 ml/min | Neonatal Intensive Care (NICU) |
Clinical Benefits of Tuoren Butterfly IV Cannulas
- Supplied with Heparin Cap: Pre-packaged with a self-sealing rubber heparin injection stopper for safe, intermittent intravenous boluses and clot prevention.
- Low-Profile Anatomical Fit: Slim winged design sits flush against the skin, drastically reducing mechanical leverage and accidental dislodgement.
- Atraumatic Venipuncture: Micro-polished tri-bevel needle tip minimizes insertion force and reduces vessel endothelial injury.
- Smooth Catheter Transition: Precision-tapered PTFE catheter tip enters cleanly without peeling, curling, or causing patient discomfort.
- Hospital Standard Packaging: 50 pieces per inner dispenser box and 1,000 pieces per shipping carton for simplified hospital inventory management.
For ported alternatives with a dedicated top injection valve, view our Tuoren IV Cannula with Injection Port.
Clinical Application & Heparin Lock Technique
The Tuoren Butterfly IV Cannula offers clinical advantages in specialized departments such as pediatrics, oncology, and neonatal units where bulky injection ports can press against fragile skin or cause pressure sores. The inclusion of a sterile Heparin Cap provides nurses and doctors with immediate access for periodic saline or heparin flushes, maintaining catheter patency during drug administration intervals without requiring line replacement. Master shipping cartons of 1,000 pieces (comprising 20 boxes of 50 pieces each) ensure optimal shelf-stacking, protection against moisture, and high compliance with procurement tenders throughout Pakistan.
Frequently Asked Questions on Butterfly Cannula Procurement
Q1: Does this butterfly cannula come with a Heparin Cap included?
Yes. Each sterile blister pack is supplied with an integrated/included Heparin Cap, allowing clinicians to perform intermittent heparin flushes and injections immediately without purchasing separate caps.
Q2: What are the packaging quantities per box and carton?
Supplied in boxes of 50 pieces and master shipping cartons containing 1,000 pieces (20 inner boxes), standardized for institutional procurement and wholesale hospital distribution.
Q3: What regulatory certifications does Tuoren hold in Pakistan?
Tuoren Butterfly IV Cannulas are CE marked, manufactured in accordance with ISO 13485:2016 standards, and fully registered with the Drug Regulatory Authority of Pakistan (DRAP) as Class IIb medical devices.
Tender & Wholesale Hospital Procurement:
M. Islam & Sons is an authorized direct distributor supplying provincial health departments, pediatric wards, and private hospitals across Pakistan. Inquire with our sales desk for bulk carton pricing, tender documentation, and evaluation samples.
Additional information
| Gauge / Size | 16G (Grey), 18G (Green), 20G (Pink), 22G (Blue), 24G (Yellow), 26G (Violet) |
|---|
